HDP Valspar Customized Brown 0.50-1.0mm Z275 PPGI Pre Painted Color Coating Steel Coils DX51D For Roofing Panel

Product Categories
Shandong Decho Building Materials Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

HDP Valspar Customized Brown 0.50-1.0mm Z275 PPGI Pre Painted Color Coating Steel Coils DX51D For Roofing Panel

  • 1
  • 2
  • 3

Brand Name : Decho Building Materials

Model Number : S320GD PRE-PAINTED GAVANIZED STEEL

Certification : MILL TEST CERTIFICATE

Place of Origin : China

MOQ : 25 TONS

Price : USD 750~1050

Payment Terms : L/C, T/T

Supply Ability : 500 tons per day

Delivery Time : 30~45days

Packaging Details : Standard Exporting Packing(Eye to Side) , No pallet Vertical Packing (Eye to Sky) with Wooden Pallet, Horizontal Packing (Eye to Side) with Wooden Pallet

Paint Surface : Customized Brown

thickness : 0.50~1.2mm

width : 1200mm

steel grade : S320GD/DX51D

PAINT SYSTEM : HDF

Paint Brand : PPG/Valspar/Beckers

Contact Now



Product details:

The pre-painted galvanized steel coils are a product obtained by subjecting a hot-dipped galvanized steel sheet to a surface chemical treatment, applying organic coating on the surface, followed by baking and curing.



Environmentally friendly, recyclable: green manufacturing, the product does not pollute, does not contain formaldehyde, does not produce construction waste and is recyclable.



Application areas:

In the construction sector: manufacture of exterior and interior products such as metal chipboard, corrugated sheets, sandwich panels, profiles, metal ceilings, skirting boards, decorative panels inside heated and unheated rooms, elevators, doors, window shutters, shelves, etc.

in the automotive industry: for the manufacture of exterior and interior body parts (car doors, car shoes, oil filters, dashboards, windshield wipers, etc.)

In the manufacture of household appliances, furniture and consumer goods: metal furniture, lighting equipment, shelving, radiators, car doors, car boots, etc.

PPGI is widely used for column and beam construction, civil engineering and decoration. Colored corrugated sheets are robust, useful and aesthetically pleasing. PPGL guarantees that buildings, cars and household appliances will retain their shine for years to come.



We manufacture thickness is 0.13-0.8 mm, width is 600-1250 mm, and PE, SMP,HDP and PVDF painted steel coil to meet customer needs.



The top finish coating is larger than 20μm to prevent the intrusion of corrosive media. Due to the different anti-corrosion mechanisms of primer and finish coating, not only the total coating thickness should be guaranteed, but also the thickness of primer (>5μm) and finish coating (>15μm).

PVDF pre-painted steel coil requires a thicker coating. It provides a longer service life. The requirements for the backside paint coating depend on the application, and the sandwich panel only requires a layer of primer. The formed steel plate requires two coats. The thickness is at least greater than 10 μm.

Polyester (PE) coating is suitable for ordinary residential roofing, the price is the cheapest, and it cannot withstand harsh environments. Silicone Modified Polyester (SMP) coating contains high weathering and super high weathering paints which can be applied in areas of high heat and cold, humid heat, and extreme cold. Polyvinylidene Difluoride (PVDF) coating has strong corrosion resistance, strong heat resistance, and the highest price. It is used in countries with humid heat, high temperatures, s and more rain.

Steel Grade:

EN10346-DX51D/ DX52D/ DX53D, S250GD/280GD/350GD/550GD, ASTM A527M, CS-B, SS255-SS550



Paint Brand:

Valspar



Loading Port:

Qingdao/Tianjin Port



 Thickness
 GI 0.20mm~1.70mm                GL 0.20mm~3.0mm
 Width
 600mm~1500mm
 Zink-Coating
 Z40~Z275g/㎡                              AZ30~AZ200g/㎡
 Paint Structure
 2/1, 2/2, 3/2, 3/3
Paint Coating
 Top side 15μm~55μm               Back side 5μm~30μm



Structural Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
30,33,36,40 0.25 0.9 0.035 0.04     0.2 0.2 0.15 0.06 0.008 0.008 0.025
36T2,45-80 0.25 1.35 0.035 0.04     0.2 0.2 0.15 0.06 0.008 0.008 0.025
45T2 .02- 0.08 .30- 1.0 .03- .07 0.025 .02- .08 0.6 0.2 0.2 0.15 0.06 0.008 0.008 0.025 .01- .03



HSLA Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
45C1 0.22 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
45C2 0.15 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C1 0.23 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C2 & 55C2 0.15 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
55C1 0.25 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C1 & 65C1 0.26 1.5 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C2 & 65C2 0.15 1.5 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
70C1 0.26 1.65 0.04 0.04     0.2 0.2 0.15 0.16 0.005 0.005 0.005
70C2 0.15 1.65 0.04 0.04     0.2 0.2 0.15 0.16 0.005 0.005 0.005



Common Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
CSA 0.1 0.6 0.03 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSB 0.02-.15 0.6 0.03 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSC 0.08 0.6 0.1 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
BH 0.012 1.5 0.12 0.03     0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSA 0.1 0.5 0.02 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSB 0.02-.15 0.5 0.02 0.03     0.2 0.2 0.15 0.06 0.008 0.008 0.025
DDS 0.06 0.5 0.02 0.025 .01   0.2 0.2 0.15 0.06 0.008 0.008 0.025
EDDS 0.02 0.4 0.02 0.02 .01*   0.2 0.2 0.15 0.06 0.1 0.1 0.15

HDP Valspar Customized Brown 0.50-1.0mm Z275 PPGI Pre Painted Color Coating Steel Coils DX51D For Roofing Panel
HDP Valspar Customized Brown 0.50-1.0mm Z275 PPGI Pre Painted Color Coating Steel Coils DX51D For Roofing Panel
HDP Valspar Customized Brown 0.50-1.0mm Z275 PPGI Pre Painted Color Coating Steel Coils DX51D For Roofing Panel
