Wood Grain Printech Color Coated Coil PPGL Steel Coil Z275 PVDF DX51D

Brand Name : Decho Building Materials

Model Number : S320GD PRE-PAINTED GAVANIZED STEEL

Certification : MILL TEST CERTIFICATE

Place of Origin : China

MOQ : 50 TONS

Price : USD 780~1050

Payment Terms : L/C, T/T

Supply Ability : 500 tons per day

Delivery Time : 30~45days

Packaging Details : Standard Exporting Packing(Eye to Side) , No pallet Vertical Packing (Eye to Sky) with Wooden Pallet, Horizontal Packing (Eye to Side) with Wooden Pallet

Surface Color : Wood Grain

thickness : 0.5mm~1.2mm

AZ-coating : AZ 150~275 g/㎡

steel grade : S320GD

STEEL GRADE : DX51D

PAINT SYSTEM : PVDF

Contact Now

Printech colorful Wood 0.50~1.2mm Z275 PPGI coil coated steel PVDF DX51D use for cladding or Roofing



Product details:

PPGL, also known as coated laminated coil or color-coated laminated coil, is a flat steel product with a protective decorative coating. The polymer coating is available in a wide range of colors, matte, glossy or with natural decorative finishes (granite, wood, etc.). Organically coated galvanized steel is corrosion-resistant, has excellent mechanical properties and can be formed, pressed or stamped.



PVDF Color Coated Sheet adopts PVDF polyester coating with good durability, adopts high molecular weight resin, with less polymer branched chain, stable bonding, not easy to photolysis, so it is not easy to chalking and high gloss. The main performance of high weathering polyester is strong weather resistance and corrosion resistance, mainly used for long sunshine time, high dryness, or large temperature difference between day and night, strong humidity and other harsh areas, wide range of uses.



Advantages:

Clear and realistic grain, easy processing and molding, corrosion resistance, energy saving and environmental protection, easy to install, safety, etc.



Application areas:

Widely used in office buildings, commercial spaces, hospitals, star hotels, airports, subways and other large public buildings.



Steel Grade:

EN10346-DX51D/ DX52D/ DX53D, S250GD/280GD/350GD/550GD, ASTM A527M, CS-B, SS255-SS550



Paint Brand:

Valpar, AkzoNobel, PPG, Beckers



Paint Coating Patterns:

Gloss Colors - RAL Code



 Thickness
 GI 0.20mm~1.70mm                GL 0.20mm~3.0mm
 Width
 600mm~1500mm
 Zink-Coating
 Z40~Z275g/㎡                              AZ30~AZ200g/㎡
 Paint Structure
 2/1, 2/2, 3/2, 3/3
Paint Coating
 Top side 15μm~55μm               Back side 5μm~30μm




Structural Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
30,33,36,40 0.25 0.9 0.035 0.04     0.2 0.2 0.15 0.06 0.008 0.008 0.025
36T2,45-80 0.25 1.35 0.035 0.04     0.2 0.2 0.15 0.06 0.008 0.008 0.025
45T2 .02- 0.08 .30- 1.0 .03- .07 0.025 .02- .08 0.6 0.2 0.2 0.15 0.06 0.008 0.008 0.025 .01- .03



HSLA Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
45C1 0.22 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
45C2 0.15 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C1 0.23 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C2 & 55C2 0.15 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
55C1 0.25 1.35 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C1 & 65C1 0.26 1.5 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C2 & 65C2 0.15 1.5 0.04 0.04     0.2 0.2 0.15 0.06 0.005 0.005 0.005
70C1 0.26 1.65 0.04 0.04     0.2 0.2 0.15 0.16 0.005 0.005 0.005
70C2 0.15 1.65 0.04 0.04     0.2 0.2 0.15 0.16 0.005 0.005 0.005



Common Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
CSA 0.1 0.6 0.03 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSB 0.02-.15 0.6 0.03 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSC 0.08 0.6 0.1 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
BH 0.012 1.5 0.12 0.03     0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSA 0.1 0.5 0.02 0.035     0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSB 0.02-.15 0.5 0.02 0.03     0.2 0.2 0.15 0.06 0.008 0.008 0.025
DDS 0.06 0.5 0.02 0.025 .01   0.2 0.2 0.15 0.06 0.008 0.008 0.025
EDDS 0.02 0.4 0.02 0.02 .01*   0.2 0.2 0.15 0.06 0.1 0.1 0.15




 Wood Grain Printech Color Coated Coil PPGL Steel Coil Z275 PVDF DX51DWood Grain Printech Color Coated Coil PPGL Steel Coil Z275 PVDF DX51DWood Grain Printech Color Coated Coil PPGL Steel Coil Z275 PVDF DX51D
